| Overall Length | 9,390 mm |
| Overall Width | 2,780 mm |
| Total Height (Boom Top) | 3,040 mm |
| Total Height (Cab Top) | 3,120 mm |
| Arm Length | 2,900 mm |
| Boom Length | 5,700 mm |
| Counterweight Ground Clearance | 1,065 mm |
| Min. Ground Clearance | 466 mm |
| Turning Radius Of Vehicle Tail | 2,720 mm |
| Ground Contact Length Of Track | 3,445 mm |
| Track Shoe Length | 4,260 mm |
| Track Gauge | 2,180 mm |
| Track Width | 2,780 mm |
| Track Shoe Width | 600 mm |
| Swing Frame Width | 2,700 mm |
| Max. Digging Height | 9,275 mm |
| Max. Dumping Height | 6,560 mm |
| Max. Digging Depth | 6,515 mm |
| Max. Vertical Wall Digging Depth | 5,915 mm |
| Max. Digging Reach | 9,865 mm |
| Max. Digging Reach At Ground Level | 9,680 mm |
| Min. Swing Radius | 3,630 mm |
| Max. Height At Min. Swing Radius | 7,670 mm |
| Distance From Swing Center To Tail | 2,720 mm |
| Counterweight Height | 2,120 mm |
| Ground Length (During Transportation) | 4,840 mm |
